709 Micro Gear box for 010 motor

Micro Gear Box with 3.3 to 1 ratio for 010 brushless motor

Designed for Astro Brushless 010
Reduction Ratio3.3 to 1
Output Gear43 tooth
Pinion Gear 13 tooth
Motor shaft 1/8 inch diameter
Prop Shaft3/16 inch diameter
Prop Nut10 x 32
Housing Aluminum
BearingsBall Bearings
Firewall Mount11x1 mm Nut
Motor Screws4-40
Motor Centers5/8 inch
Gear Box Weight1/2 ounce
Gear Box length1/2 inch

Please be sure to lubricate the metal gears before running the

gearbox at high power and after every hour of use. Any light grease will

work fine. We use bike grease or white lithium grease. Make sure there is

proper clearance between the gears. To set the clearance place a narrow

strip of computer paper between the pinion and spur gears,press the gears

together, then tighten the mounting screws. Then turn the shafts to eject the

paper strip and go play!
